Хирургический лазер CHEESE PLUS

для стоматологиидля стоматологической фотостимуляциидля фотостимуляции в ортопедии

Overview
CHEESE PLUS is a mini multi-wavelength medical laser system offering combinations of visible and near-infrared wavelengths for clinical, dental, therapy and veterinary applications. The system supports four wavelengths (450nm, 650nm, 810nm and 1064nm) in various model configurations. FDA 510(k) Number K230047.

Wavelengths and general uses

• 450nm: suitable for certain soft tissue surgeries (excision, incision) where reduced bleeding and limited tissue damage accelerate healing and reduce patient discomfort.
• 650nm (often referenced as 635nm/650nm): used for biostimulation and pain treatment; promotes healing, tissue regeneration, reduces inflammation and relieves pain.
• 810nm: penetrates deeper tissues and is appropriate for deep tissue surgery (e.g., root canal treatment, oral surgery), allowing deeper penetration with minimized collateral damage.
• 1064nm: near-infrared wavelength for deep tissue procedures (pulpitis treatment, bone tissue surgery), effective in alleviating inflammation and pain and promoting healing.

Dentistry — primary applications
The CHEESE PLUS wavelengths have distinct dental applications: soft tissue surgeries, incision/excision with reduced bleeding (450nm); biostimulation and pain relief (650nm); deep tissue and oral surgeries including root canal work (810nm); and deep pulp and bone procedures (1064nm).

Therapy — rehabilitation and pain management
The system is used in rehabilitation and pain management. Key therapeutic benefits described include cell metabolism stimulation, enhanced blood circulation, immune function support and deep-tissue biostimulation to reduce inflammation and pain. Specific wavelength notes:

• 650nm: stimulates cell metabolism, improves blood circulation, treats musculoskeletal pain, ligament/tendon injuries and spinal disorders.
• 810nm: deep penetration for biostimulation to reduce inflammation and relieve musculoskeletal pain and tendonitis.
• 980nm (when present in therapy variants): strong tissue penetration for deep tissue injury treatment, fractures and spinal disorders, potential neurological therapy applications.
• 1064nm: exceptional penetration depth for deep muscle, bone and joint treatments (lumbar strain, knee pain, arthritis).

Product family and model variants
CHEESE PLUS is offered in multiple order models and wavelength/power configurations to suit dentistry, therapy and veterinary uses. Models and configurations vary by included wavelengths, pilot beam, maximum power and supported operation modes.

Technical specifications (extracted tables)
Dentistry table
Parameter | CHEESE PLUS (CP18G) | CHEESE PLUS (CP13G) | CHEESE PLUS (CP23G)
Order Model | CP18G | CP13G | CP23G
Wavelength | 635nm + 445nm + 810nm | 635nm + 445nm + 1064nm | 635nm + 445nm + 810nm + 1064nm
Maximum Power | 200mW + 3W + 15W | 200mW + 3W + 10W | 500mW + 3W + 10W + 10W
Pilot Beam | 532nm | 532nm | 532nm
Operation Mode | CW, Repeat Pulse | CW, Repeat Pulse | CW, Repeat Pulse
Pulse Duration | 10μs – 3s | 10μs – 3s | 10μs – 3s
Repetition Rate | 0.2Hz – 20KHz | 0.2Hz – 20KHz | 0.2Hz – 20KHz

Therapy table
Parameter | CHEESE PLUS (CP20RT) | CHEESE PLUS (CP20DRT)
Order Model | CP20RT | CP20DRT
Wavelength | 635nm + 980nm | 635nm + 810nm + 980nm
Maximum Power | 500mW + 20W | 500mW + 10W + 10W
Pilot Beam | 635nm | 635nm
Operation Mode | CW, Repeat Pulse, IPS | CW, Repeat Pulse, IPS
Pulse Duration | 10μs – 3s | 10μs – 3s
Repetition Rate | 0.2Hz – 20KHz | 0.2Hz – 20KHz

Veterinary table
Parameter | CHEESE PLUS (CP20RV) | CHEESE PLUS (CP20RV) | CHEESE PLUS (CP25RV)
Order Model | CP20RV | CP20RV | CP25RV
Wavelength | 635nm + 980nm | 635nm + 810nm + 980nm | 635nm + 450nm + 810nm + 980nm
Maximum Power | 500mW + 20W | 500mW + 10W + 10W | 500mW + 5W + 10W + 10W
Pilot Beam | 635nm | 635nm | 635nm
Operation Mode | CW, Repeat Pulse, IPS | CW, Repeat Pulse, IPS | CW, Repeat Pulse, IPS
Pulse Duration | 10μs – 3s | 10μs – 3s | 10μs – 3s
Repetition Rate | 0.2Hz – 20KHz | 0.2Hz – 20KHz | 0.2Hz – 20KHz

Notes
- Operation modes referenced: CW (continuous wave), Repeat Pulse, IPS (when indicated).
- Pulse duration range: 10 μs to 3 s; repetition rate range: 0.2 Hz to 20 KHz.

caractéristiques / spécifications techniques

• Commercial name / series: CHEESE PLUS
• Wavelength options: combinations of 445nm (or 450nm), 635nm (650nm referenced), 810nm, 980nm and 1064nm depending on model
• FDA 510(k): K230047
• Pilot beam: typically 532nm or 635nm depending on model
• Operation modes: CW, Repeat Pulse, IPS (in some therapy/veterinary models)
• Pulse duration: 10 μs – 3 s
• Repetition rate: 0.2 Hz – 20 KHz
• Example dentistry model codes: CP18G, CP13G, CP23G
• Example therapy model codes: CP20RT, CP20DRT
• Example veterinary model codes: CP20RV, CP25RV
• Maximum power: model-dependent (examples in tables: up to combinations like 200mW + 3W + 15W; 500mW + 3W + 10W + 10W; 500mW + 20W, etc.)
